Grupy API

The Grupy API coordinates shared payment journeys between a group organizer and multiple participants, it provides the transaction coordination layer, participant state, authorization decisions, contribution tracking and reconciliation instructions.

Responsibility Boundary

Clear segregation of duties ensures PCI compliance and operational security across partner systems:

API Fundamentals

Current Base URL

This works for both test and live environments. Your API keys determine which environment you're using.

Endpoints

Request Conventions

• Content Type: application/json (UTF-8)
• Maximum Body Size: 1 MB limit per request
• Dates & Times: ISO 8601 in UTC, for example 2026-08-02T14:30:00Z
• Phone Numbers: E.164 digits, for example 27821234567
• Currency: Uppercase ISO 4217 code, Phase 1 is ZAR
• Monetary Amounts: Integer minor units only ending in Minor (e.g. 2400000 for ZAR 24,000.00)
• Identifiers: Opaque strings; partners must not infer business meaning from format

Authentication & Request Integrity

The live partner endpoint (/partner/clickatell/events) requires HMAC-SHA256 request signing using CLICKATELL_PARTNER_SECRET. The secret is exchanged via secure channel and never exposed in logs or documentation.

Content-Type: application/json
X-Grupy-Timestamp: 1785386400
X-Grupy-Signature: sha256=<lowercase-hex-hmac>
Idempotency-Key: clickatell-event-evt_01JXYZ

Signature Calculation Input: <timestamp>.<exact-raw-request-body>
Signing Formula: hex(HMAC-SHA256(partner_secret, signature_input))

const crypto = require('crypto');

const timestamp = Math.floor(Date.now() / 1000).toString();
const rawBody = JSON.stringify(payload);
const signature = crypto
  .createHmac('sha256', partnerSecret)
  .update(`${timestamp}.${rawBody}`)
  .digest('hex');

// Send HTTP Request with headers:
// X-Grupy-Timestamp: timestamp
// X-Grupy-Signature: sha256=${signature}

Requests with a missing or invalid signature are rejected. Timestamp must be within 300 seconds (5 minutes) of Grupy's server clock.

Credential Rules

• Use a different credential per partner and environment.
• Store credentials strictly in a server-side secret manager.
• Never place credentials in browser, mobile app, URL, analytics, or source repo.
• Rotate credentials immediately if exposure is suspected.
• Contact Grupy before rotating active production credentials to coordinate cutover.

Idempotency & Duplicate Prevention

Every state-changing event requires a globally unique and stable event identifier passed via the Idempotency-Key header.

• Use 8 to 128 characters (letters, digits, ., _, :, -).
• Reuse the exact same key when retrying the exact same request.
• Never reuse a key for a corrected or different payload.
• An exact replay returns the original response and includes X-Idempotent-Replay: true.
• Reusing a key with different content returns HTTP 409 idempotency_payload_mismatch.
• A request still processing returns HTTP 409 idempotency_request_in_progress.

Money & Precision

Grupy represents all monetary values strictly as integer minor units. Floating-point numbers and decimal money strings are prohibited on the API boundary.

{
  "amountMinor": 123456,
  "currency": "ZAR"
}

Event & Action Model

The Grupy Partner API is event-driven. Events report actions in partner channels; Grupy responses return instructions for the next action.

{
  "eventType": "flow_completed",
  "eventId": "evt_demo_01JXYZ",
  "phoneNumber": "27821234567",
  "contactId": "partner_contact_123",
  "sessionId": "partner_session_123",
  "flowName": "grupy_onboarding",
  "flowData": {}
}

{
  "received": true,
  "duplicate": false,
  "channel": "whatsapp",
  "recipient": "27821234567",
  "contactId": "partner_contact_123",
  "sessionId": "partner_session_123",
  "messages": [
    {
      "type": "text",
      "text": "Your request was accepted."
    }
  ],
  "nextAction": "show_main_menu"
}

Core Event Families

Response & Messaging Delivery Model

The primary Phase 1 delivery model is synchronous:

1. Clickatell sends one signed event to POST /partner/clickatell/events.
2. Grupy processes the event and returns messages, nextAction, routing information, and Flow/template parameters in the HTTP response.
3. Clickatell renders and delivers the corresponding WhatsApp screen, message, invitation, or Chat2Pay action.
4. If delivery fails, Clickatell retries the original event with the same eventId and Idempotency-Key; Grupy returns the cached response without duplicating transactions.

Asynchronous Outbound Alternative: If Clickatell requires Grupy to invoke an outbound send-message API rather than receiving synchronous response instructions, Clickatell must supply the outbound endpoint, OAuth/bearer scheme, message schemas, and delivery webhooks.

WhatsApp Delivery Policy

• Session Messages: Responses to active inbound user interactions use session messages while the 24-hour customer-service window is open.
• Template Messages: Out-of-window messages (e.g. invitations, payment reminders) use approved WhatsApp templates such as grupy_group_invitation_v1.
• Window Management: Clickatell owns 24-hour window tracking and template rendering. Grupy returns stable template keys and parameter maps.

Clickatell Native Payload Mapping

Clickatell may send canonical Grupy field names directly or use the accepted aliases below. Ambiguous or unknown fields produce validation errors rather than guessed updates.

Current Pilot Event Payloads

{
  "eventType": "flow_completed",
  "eventId": "onboarding_001",
  "phoneNumber": "27821234567",
  "contactId": "ct_contact_123",
  "flowName": "grupy_onboarding",
  "flowData": {
    "displayName": "Lebo Mokoena",
    "email": "lebo@example.com",
    "pin": "482604",
    "pinConfirmation": "482604",
    "consent": {
      "termsAccepted": true,
      "privacyAccepted": true,
      "marketingOptIn": false
    }
  }
}

{
  "eventType": "flow_completed",
  "eventId": "pin_001",
  "phoneNumber": "27821234567",
  "flowName": "grupy_pin",
  "flowData": {
    "pin": "482604",
    "requestedAction": "create_group"
  }
}

{
  "verified": true,
  "authorizationExpiresInSeconds": 300,
  "nextAction": "create_group"
}

{
  "eventType": "payment_method_ready",
  "eventId": "payment_method_001",
  "phoneNumber": "27821234567",
  "provider": "chat2pay",
  "customerReference": "cust_123",
  "paymentMethodReady": true
}

{
  "eventType": "flow_completed",
  "eventId": "create_001",
  "phoneNumber": "27821234567",
  "flowName": "grupy_create_payment",
  "flowData": {
    "title": "Weekend accommodation",
    "totalAmountMinor": 2400000,
    "dueOn": "2026-08-15",
    "splitMode": "equal",
    "includeOrganizer": true,
    "members": [
      "27825550101",
      "27825550102"
    ],
    "settlementDestination": {
      "type": "organizer",
      "label": "Lebo Mokoena"
    }
  }
}

{
  "received": true,
  "nextAction": "send_invitations",
  "group": {
    "referenceCode": "GRP-1234ABCD",
    "status": "pending_members",
    "includeOrganizer": true
  },
  "invitations": [
    {
      "to": "27825550101",
      "action": {
        "type": "open_flow",
        "flowKey": "join_group",
        "parameters": {
          "groupReference": "GRP-1234ABCD"
        }
      }
    }
  ]
}

{
  "eventType": "message",
  "eventId": "message_001",
  "phoneNumber": "27821234567",
  "action": "join GRP-1234ABCD"
}

{
  "eventType": "chat2pay_payment_succeeded",
  "eventId": "payment_001",
  "phoneNumber": "27825550101",
  "groupReference": "GRP-1234ABCD",
  "paymentReference": "c2p_payment_123",
  "amountMinor": 80000,
  "currency": "ZAR",
  "status": "succeeded",
  "provider": "chat2pay"
}

Payment Lifecycle & Events

Supported Chat2Pay lifecycle events:

{
  "eventType": "payment_pending",
  "eventId": "payment_event_001",
  "phoneNumber": "27825550101",
  "groupReference": "GRP-1234ABCD",
  "attemptReference": "c2p_attempt_123",
  "paymentReference": null,
  "amountMinor": 80000,
  "currency": "ZAR",
  "provider": "chat2pay",
  "occurredAt": "2026-08-06T10:15:30Z",
  "expiresAt": "2026-08-06T10:30:30Z"
}

Errors, Retries & HTTP Contract

Standard Error Response Shape

{
  "error": "machine_readable_code",
  "message": "Safe partner-facing explanation",
  "correlationId": "corr_demo_123"
}

Retry & Timeout Guidance

• Every event must contain a unique, stable eventId.
• Retries must reuse the original eventId and Idempotency-Key.
• Clickatell may retry transient 5xx responses with exponential backoff.
• Do not retry corrected 4xx client errors under the same eventId.
• Respect Retry-After headers on 429 responses.

Security & Data Handling

Security Commitments

• All partner traffic requires HTTPS (TLS 1.2+).
• State-changing events require HMAC-SHA256 authenticated server requests.
• Event replay is protected using signed timestamps and idempotency keys.
• Sensitive values are redacted from normal service logs.
• Raw cardholder data is never accepted on the Grupy partner API.

Prohibited Data

Clickatell & partners must NEVER send any of the following fields to Grupy:

• Full credit card number or PAN
• CVV / CVC security codes
• Card, banking, or device OTPs
• Banking PIN or card PIN
• Masked card numbers, expiry dates, or card fingerprints
• Raw card/token references on payment readiness events

Grupy PIN Security

The Grupy authorization PIN is a 6-digit application credential (not a card/bank PIN). Validating a PIN establishes a 5-minute (300s) server-side authorization window (authorizationExpiresInSeconds: 300). 5 failed PIN attempts lock verification for 15 minutes.

Clickatell Decisions Required

Key technical items and design decisions required from Clickatell prior to production go-live:

• Confirm production callback authentication and whether HMAC signing (X-Grupy-Signature) is supported.
• Provide actual Chat Flow request and response schemas.
• Provide Chat2Pay link-generation endpoint, authentication, expiry fields, callback event IDs, timestamp semantics, and exact minor-unit/decimal conversion requirements.
• Confirm 3DS/SCA browser behavior and supply sandbox cards for success, failure, timeout, and challenge tests.
• Confirm WhatsApp 24-hour window indicators, approved template names, and failed-delivery retry responsibilities.
• Confirm whether Grupy returns a synchronous screen instruction or calls a separate Clickatell send-message API.
• Provide Chat2Pay payment-method-ready, payment-created, succeeded, failed, expired, reversed, refunded, disputed, and payout callbacks.
• Confirm that Clickatell retains token ownership; also confirm the merchant account, settlement account, fees, reconciliation reports, and refund authority.
• Confirm whether saved-card repeat payments require a user button, text approval, 3DS, or another authorization.
• Confirm webhook retry schedule, maximum retention period, source IP ranges, and request timeout.
• Confirm the official WhatsApp business number, display name, templates, and support escalation path.
